GENERATOR MODEL |
GPED-65EK |
| MAX KW POWER | 6.0 |
| KW POWER | 5.0 |
| AMPS 120 VAC | 40 |
| AMPS 240 VAC | 20 |
| GENERATOR REGULATION | 5 % VOLTAGE REGULATION WITH MECHANICAL ENGINE GOVERNOR |
| FREQUENCY REGULATION | 5 %, (3 HERTZ) FREQUENCY REGULATION ON ALL MODELS |
| ENGINE MODEL | KOHLER KD440 EPA/CARB TIER IV CERT. & 3 YEAR LIMITED WARRANTY |
| ENGINE START METHOD | 12 VOLT ELECTRIC START WITH BUILT-IN BATTERY CHARGER |
| ENGINE HORSEPOWER | 9 HP INTERMITTENT USE, 8 HP CONTINUOUS USE |
| SUPER QUIET MUFFLER | ALL MODELS : SPECIAL RESIDENTIAL STYLE MUFFLER FOR OPTIMUM SOUND REDUCTION |
| ENG. CU. CENTIMETER | 440 |
| TOTAL ENGINE CYLINDERS | 1 |
| LOW OIL PROTECTION | STANDARD PROTECTION ON ALL MODELS |
| db(A) AT 7 METERS | 85 |
| FUEL TANK GAL. (LITERS) | 4 GALLON (15 LITER) CROSSLINK POLYETHYLENE TANK |
| 3/4 LOAD RUN TIME (HRS) | 8 HOURS |
| FUEL USE, GAL/HR | <1/2 LOAD = .40 GPH> <3/4 LOAD = .52 GPH> |
| FUEL INJECTION SYSTEM | DIRECT |
| FULL PRESSURE OIL LUBE. WITH SPIN ON OIL FILTER |
YES, PLUS 1.6 QT. OIL SUMP |
| ELECTRIC MOTOR STARTING | 1 1/2 HP, CODE G ELECTRIC MOTOR |
| GENERATOR DESIGN | PORTABLE |
| MAGNETIC CIRCUIT BREAKER | STANDARD PROTECTION ON ALL 1 PHASE MODELS |
| VOLTMETER – HOUR METER | VOLTMETER AND HOUR METER IS INSTALLED ON ALL MODELS |
|
120 VOLT RECEPTACLE
|
(4) NEMA 5-15R 120 VOLT, RECEPTACLES WITH GFCI PROTECTION |
| (1) NEMA L5-30R, 30 AMP 3 WIRE TWIST-LOCK | |
| COLD START GLO PLUGS | OPTIONAL |
| 240 VOLT RECEPTACLE | (1) NEMA 14-30R, 30 AMP 4 WIRE |
| LENGTH, INCHES | 28 |
| WIDTH, INCHES | 22 |
| HEIGHT, INCHES | 23 |
| GEN-SET SHIP WEIGHT, LBS. | 207 |
| CU. FEET SHIP BOX | 10 |
